LOR Items Network LOR ID Controller Dip Switch Settings
Standard 64 Layout Regular 01-04 CTB16PC Set with Hardware Utility
RGB Pixel Mini Trees Regular 05 Pixie 0000 0101
RGB Pixel Stars Regular 0F Pixie 0000 1111
RGB Candy Canes Regular 15 Pixie 0001 0101
RGB Pixel Stakes Regular 1F Pixie 0001 1111
RGB Wreath Regular 23 Pixie 0010 0011
RGB Floods Regular 24 Pixie 0010 0100
Legacy Dumb RGB Regular 25 CMB24D 0 0010 0101
RGB Arch 1-4 Regular 26 Pixie 0010 0110
RGB Arch 5-8 Regular 2A Pixie 0010 1010
Dumb Star Burst Regular 2E CMB24D 0 0010 1110
Dumb Star Burst Regular 2F CMB24D 0 0010 1111
RGB Pixel Tree Left Aux A 30 Pixie 0011 0000
RGB Pixel Tree Left Star Aux A 34 Pixie 0011 0100
RGB Pixel Tree Right Aux A 35 Pixie 0011 0101
RGB Pixel Tree Right Star Aux A 39 Pixie 0011 1001
RGB Snowflakes Aux A 40 Pixie 0100 0000
RGB Spinners Aux A 44 Pixie 0100 0100
RGB Pixel Star Burst Left Aux A 48 Pixie 0100 1000
RGB Pixel Star Burst Right Aux A 4C Pixie 0100 1100

Intelligent DMX Items Universes Universe Reserved *
RGB Pixel Mega Tree PMT1 1-6 1-10
RGB Bulbs 11-17 11-20
RGB Icicles 21-29 21-29
RGB Singing Tree 1 30-31 30-31
RGB Singing Tree 2 32-33 32-33
RGB Singing Tree 3 34-35 34-35
RGB Singing Tree 4 36-37 36-39
RGB Candy Canes 40-46 40-46
RGB Singing Bulb 1 47-48 47-48
RGB Singing Bulb 2 49-50 49-50
RGB Singing Bulb 3 51-52 51-52
RGB Singing Bulb 4 53-54 53-54
RGB Ribbon Tree 60-69 60-69
RGB Ribbon Screen 70-79 70-79
RGB Pole P1 80-81 80-81
RGB Pole P2 82-83 82-83
RGB Pole P3 83-84 83-109
RGB Matrix M1 110-114 110-114
RGB Matrix M2 114-118 114-118
RGB Matrix M3 119-131 119-149
RGB Mini Trees 1-10 150-152 150-159

* Reserved universes can be used to expand motion effects to additional props.
